Print Method

Dye Sublimation Thermal Transfer

Resolution

12 dots/mm (300 dpi)

Paper Size Capacity

152 mm (6 in.) width roll paper for print
900 sheets/roll (for 4 x 6 size prints)
450 sheets/roll (for 6 x 8 size prints)
(Same as each printable size of dye-sub print.)

Standard Print Sizes

4 x 6″
6 x 8″

Optional Print Sizes

2 x 6″
4 x 6″split
6 x 6″
5 x 7″ with 1/2″ border
6 x 8″ – 4 split print

Operating Temperature

10 to 35 degrees C

Operating Humidity

20% to 80% (RH) (There must be no condensation in both cases)

Paper Feeding

Paper feed (Roll to Cut method)

Ink Ribbon

4 x 6 size ink ribbon, 900 images/roll
6 x 8 size ink ribbon, 450 images/roll

Dimensions

290 mm (W) x 375 mm (D) x 345 mm (H)

Weight

15 kg (or less without media)

Interface

USB 2.0

Power voltage

100 to 240 V AC (Automatic switching)

Power consumption

Less than 165 W / 1.8 A at 100 V AC
Less than 165 W / 0.8 A at 220 V AC

Buffer Memory

32MB

Drivers
Mac Driver .zip / 6.06 MB
S2245 S3 Windows Driver Version 3.1 Build 390 (Updated verification to security certificate embedded in INF file processing for XP OS) .zip / 23.63 MB
Manuals
S3 Operations/User Manual .pdf / 635.99 KB
S3 Quick Installation Manual .pdf / 114.51 KB
Brochure
ItemsP/No. No. of Prints Optional Print Size
4"x6" Print Media xxxxxxx2 rolls of 4"x6" media with 900 prints per roll (1800 prints per box) (4"x6")x2, (2"x6")x2, 6"x8"
6"x8" Print Media xxxxxxx 2 rolls of 6"x8" media with 450 prints per roll (900 prints per box) (4"x6")x2, (2"x6")x2, 6"x8"
